Customized Colors
details show
| Ground penetrating radar | ||
| Work capacity: | 10 pcs channesl | |
| Engine power: | 240 HP | |
| Engine type: | Isuzu 6HK1 | |
| Axle drive: | 4x2 | |
| Gear box: | FAST 8-shift | |
| Remarks: | 3m depth of detection | |
| Number of channels | Pcs | 10 |
| Depth of detection | m | ≥3 |
| Detection speed | km/h | ≥20 |
| Center frequency | Hz | 400M |
| Single-channel radar (optional) | ||
| Number of channels | Pcs | 1 |
| Depth of detection | m | ≥3 |
| Center frequency | Hz | 400M |
| Positioning system | ||
| Single point targeting | Horizontal 1.5m, vertical 3.0m | |
| RTK | Horizontal 0.8cm+1ppm, vertical 1.5cm+1ppm | |
| Maximum travel speed | km/h | 130 |
| Dimensions (L×W×H) | mm | 5680×2011×2736 |
| Total mass | kg | 4200 |
